Ferrisburg quarry · flown 06:12 · 41 min
Drodig flies your site, processes the imagery, and hands back a survey-grade terrain model, orthomosaic, and cut/fill volumes. No rover, no crew standing around.
±18 mm
VERTICAL RMSE
4 hrs
FLIGHT → DELIVERY
240 ha
PER SINGLE SORTIE
1,140
SITES SURVEYED
The flight day
01 — 06:00
Our pilot sets five RTK-tagged checkpoints around your active area. These are what your engineer will audit the model against.
02 — 06:12
A pre-planned double-grid at 80 m with 75% overlap. Machines keep working — we fly above the exclusion zone, not through it.
03 — 07:30
2,400 frames become a dense point cloud, a triangulated surface, and a 2 cm/px orthomosaic. Checkpoint residuals get reported, not hidden.
04 — 10:15
We difference the new surface against your design or last month's flight and send cut/fill by stockpile and by zone.
What lands in your inbox
Everything is delivered in the formats your civil software opens natively. No proprietary viewer, no per-seat licence.
Ground-classified DTM and full DSM.
Georeferenced 2 cm/px site plan.
Per-pile quantities with basis-of-surface notes.
Heatmap of movement since the previous flight.
Smoothed contours at your chosen interval.
Checkpoint residuals, signed by a licensed surveyor.
Accuracy, stated plainly
A drone survey is only worth what it can be checked against. We withhold two of the five ground checkpoints from processing and report the residuals on both — so the number you get is measured, not marketed.
| ID | Δ EAST | Δ NORTH | Δ ELEV | USED |
|---|---|---|---|---|
| GCP-01 | 0.009 | -0.011 | 0.014 | yes |
| GCP-02 | -0.006 | 0.008 | -0.010 | yes |
| GCP-03 | 0.012 | 0.007 | 0.017 | yes |
| CHK-01 | 0.014 | -0.013 | 0.018 | held |
| CHK-02 | -0.011 | 0.016 | -0.015 | held |
Pricing
$1,450
PER SORTIE · UP TO 60 HA
$980/flight
12-MONTH SCHEDULE
Quoted
MULTI-SITE / MULTI-REGION
Book a flight
We reply with a flight window and a fixed price, usually the same day.
Or call the dispatch desk — +1 (802) 555 0148
